Sunlight Readable 2.4 Inch 20pin IPS LCD Display High Brightness

Minimum Order Quantity : 1PCS Price : /
Packaging Details : All the products are packed in right way to keep it safe. For small sizes of products we use tray + carton, For bigger sizes we use foam slot + carton. we also design packages according to customers' requirements Delivery Time : 7-15 working days
Payment Terms : T/T Supply Ability : 300Kpcs/month
Place of Origin: ShenZhen, China Brand Name: Chenghao/Oem
Certification: ROHS、ISO9001、CE Model Number: CH240QV60A

Detail Information

Product Name: Small Tft Screen Dot Arrangement: 240x320 Dots
Viewing Direction: IPS All Viewing Direction Operating Temp: -20 ~ +70℃
Storage Temp: -30 ~ +80℃ Luminance: 1000 Cd/m2
Pin Number: 20 Pin
High Light:

20pin IPS LCD Display

,

1000cd IPS LCD Display

,

2.4inch High Brightness LCD Display

Product Description

Sunlight Readable 2.4 Inch 20pin IPS LCD Display High Brightness



Sunlight Readable 2.4 Inch Tiny Lcd Display 1000 Cd/M2 High Brightness 20pin


Quick detail of small tft display

Sunlight Readable 2.4 Inch 20pin IPS LCD Display High Brightness 0

Keyword: small portable lcd display
LCD type: 2.4”TFT
Dot arrangement: 240*(RGB)×320 dots
Display mode: IPS / Transmissive / Normally Black
Viewing Direction: 80/80/80/80
Driver IC TFT: ST7789

Luminance: 1000 cd/m2
Module size: 42.72*60.26*2.3 mm
TFT Active area: 36.72*48.96 mm
Operating temperature: -20 ~ +70 ℃
Storage temperature: -30 ~ +80 ℃
Weight: TBD g









Description of  small lcd panels



Introducing the CH240QV60A small portable LCD display – the perfect solution for your compact display needs. This high-quality display module features a 2.4” TFT LCD panel with a dot arrangement of 240*(RGB)×320 dots, offering crisp and clear visuals for your applications.

The display mode can be configured as either IPS/Transmissive/Normally Black, depending on the viewing requirements. With a viewing direction of 80/80/80/80, users can enjoy vibrant and clear visibility from multiple angles.

With luminance rated at 1000 cd/m2, this display is highly visible even in bright environments.





Sunlight Readable 2.4 Inch 20pin IPS LCD Display High Brightness 1





Measuring at 42.7260.262.3mm and weighing a simple TBD g, the CH240QV60A is small and portable, making it an ideal choice for compact devices that require reliable display solutions. It has been certified by RoHS and CE, ensuring quality and safety standards.

Operating temperatures ranging from -20 ~ +70 ℃ and storage temperatures of -30 ~ +80 ℃ make it resistant to a variety of environment conditions.

Overall, the CH240QV60A is a highly versatile and reliable display module that is ideal for a wide range of compact display applications.




Specification of small tft lcd displays



Product No CH240QV60A
Number of dots 240*320
Supplier Name Chenghao Lcd
Supplier Type Manufacture
Support for Customized Content BL,TP,Interface,Anti-glare,FPC
Life Time 20000 H
Luminance 1000 cd/m2
Display Area Size 2.4 inch



Sunlight Readable 2.4 Inch 20pin IPS LCD Display High Brightness 2




Services of color tft lcd screen

Pre-Sales Services:
Our team designs and develops solutions based on the unique requirements of each customer. We provide 24-hour service and will respond to every inquiry within 12 hours.
Post-Sales Services:
We provide customer service through Skype, phone, or email and provide videos or drawings to help solve any issues.
Our remote control service through the internet allows for real-time assistance and shortened problem-resolution time.
Our dedicated engineers ensure quick responses to any customer inquiry.


Application Of TFT LCD Module



CH240QV60A is tailored to deliver high precision and reliability requirements for use in medical devices, measurement equipment, ruggedized handheld devices, and many other applications. With RoHS and CE certificates, you can be assured of its high-quality standards.

In conclusion, the CH240QV60A is an excellent choice for buyers seeking customized color LCD modules that deliver on quality, reliability, and functionality. It caters to a wide variety of applications while maintaining exceptional performance that meets industrial, medical, and commercial needs. Get your hands on CH240QV60A and transform your projects with reliable and advanced display solutions.



In conclusion, the CH240QV60A is an excellent choice for buyers seeking customized color LCD modules that deliver on quality, reliability, and functionality. It caters to a wide variety of applications while maintaining exceptional performance that meets industrial, medical, and commercial needs. Get your hands on CH240QV60A and transform your projects with reliable and advanced display solutions.

Sunlight Readable 2.4 Inch 20pin IPS LCD Display High Brightness 3



Drowings of  small lcd monitor



Sunlight Readable 2.4 Inch 20pin IPS LCD Display High Brightness 4



FAQ



1.What is the driver IC for the TFT?
Answer: The driver IC for the TFT is ST7789.



2.What is the module size and TFT active area?
Answer: The module size is 42.7260.262.3mm and TFT active area is 36.72*48.96mm.



3.What are the operating and storage temperature ranges?
Answer: The operating temperature range is -20 ~ +70 ℃ and the storage temperature range is -30 ~ +80 ℃.



4.What is the weight of the module and does it have any certifications?
Answer: The weight of the module is yet to be determined and it has RoHS and CE certifications.



5.What is the minimum order quantity, delivery period, supply ability and payment method?
Answer: The MOQ is 1 pcs, the delivery period is 7-15 working days, the supply ability is 300K pcs/month and the payment method is T/T. We also provide custom packaging solutions for the customers.
