4.3 Inch Custom 300cd m2 IPS LCD Display 24 Bit Parallel RGB Interface

Minimum Order Quantity : 100 pcs Price : /
Packaging Details : All the products are packed in right way to keep it safe. For small sizes of products we use tray + carton, For bigger sizes we use foam slot + carton. we also design packages according to customers' requirements Delivery Time : 7-15 working days
Payment Terms : T/T Supply Ability : 200Kpcs/month
Place of Origin: ShenZhen, China Brand Name: 4.3 Inch
Certification: ROHS、ISO9001、CE Model Number: CH430WQ12D

Detail Information

Size: 4.3" INCH Dot Arrangement: 480X3(RGB)X272
Display Mode: IPS For View Module Size: 105.5(W)X67.2(H)X3.0(T)mm
Active Area: 95.04(W)X53.856(H)mm Interface: RGB
Operating Temperature: -20 ~~~ +70 Storage Temperature: -30 ~ ~~+80
Back Light: 7- White LED
High Light:

300cd m2 IPS LCD Display

,

1200cd m2 IPS LCD Display

,

300cd m2 Color LCD Display

Product Description

4.3 Inch Custom 300cd IPS LCD Display 24 Bit Parallel RGB Interface



4.3" TFT LCD Screen IPS Viewing 24-Bit Parallel RGB Interface Color Tft Lcd



Details for product:

LCD type 4.3’’TFT
Dot arrangement 480(RGB)×272
Color filter array RGB vertical stripe
Viewing Direction 80/80/80/80
Back Light 7 White LED
Weight TBD
LR Horizontal scan direction control
UD Vertical scan direction control.
Interface 24-bit Parallel RGB Interface
Display mode IPS / Transmissive / Normally Black



Tip: all of our products can be with or without touch, whatever you choose. Backlight brightness and FPC interface can be customized according to your requirements,



Prduct Application​:

Chenghao Optoelectronics can provide one-stop color TFT module solutions for various shapes, and can change FPC, pin definition, driver and motherboard according to customers' requirements. High voltage or low voltage can be achieved, the working temperature can be achieved ultra-wide temperature up to -40℃-90℃, the viewing angle can be achieved from 6:00 O’clock to full IPS.



You can choose:

1. High luminance display 300-1500cd/m2.

2. 0.96 to 10.1 inch touch display,can be remove the touch.

3. Custom available: IPS/logo/transparency hole/real hole/silk-printing color/Anti glare/Anti fingerprint/Anti reflective/touch with water/gloves touch.



Drawing:



4.3 Inch Custom 300cd m2 IPS LCD Display 24 Bit Parallel  RGB Interface 0



Packaging & Shipping:
Packaging Details:

1. All the products are packed in right way to keep it safe.

2. For small sizes of products we use tray + carton,

3. For bigger sizes we use foam slot + carton.

4. we also design packages according to customers' requirements



Shipping Details:
For small quantity orders: we ship by UPS Air-Express, or DHL/FEDEX/TNT/ EMS Express service, it is safe and fast.



Our services:

1. Why choose ChengHao Optoelectronic?
High Service Quality: OEM & ODM service; Reply in 24 hours; All of our products are up to the international quality standards
High Product Quality: Our well equipment and strict function testing in the productive process guarantee the excellent quality of each product.
Professional Manufacturer: household appliances, industrial control, medical equipment, POS machine, instruments and meters, GPS navigation, financial equipment, consumer equipment, information appliances.

2. Could I order one piece for sample to test the quality?
Yes, We recommend checking the sample before order. You could order the sample before your order.

3. May I have your catalogue and price list for trial order in MOQ quantity?
All our products are displayed on Google platform. Please take a closer look and choose the model you are interested in on our website.

4. If I order big quantity, what's the good price?
Please send the details enquiry to us, such as the item number, quantity for each item, quality request, Logo, payment terms, transport method, discharge place etc. We will make the accurate quotation to you as soon as possible.

5. What are my payment options?
For samples and small acount, it is 100% in advance.
For mass production, it is 30% in advance and 70% balance.
Welcome West Union, TT. bank account and Paypal.

6. How long will it take to ship my order?
As long as there is stock available, ChengHao Optoelectronic usually ships items in 1 to 3 working days for samples and within 7 to 15 days for customized order once receiving the confirmation of a new order. The order will not be confirmed until the payment reaches ChengHao Optoelectronic bank account. If we are temporarily out of stock, we will do our best to inform you of the estimated lead time.

7. What does your warranty cover?
ChengHao Optoelectronic product is backed by a 1-year limited warranty against manufacturing defects (material or workmanship). Missing/lost or worn out parts are not covered under our warranty.
