24 Pins Touchscreen Display Module 4.3 Inch IPS TFT Lcd For Wide Temperature

Product Description:

The CH430WQ22A-CT is a high-performance 4.3-inch TFT LCD module engineered for demanding industrial, automotive, and consumer applications. It features a landscape-oriented IPS panel with a sharp 800x480 resolution, delivering vibrant 16M-color visuals. The wide 80/80/80/80 viewing angles ensure consistent image quality from almost any direction. Integrated capacitive touch technology (IIC interface) offers a smooth and responsive user experience. Built to withstand challenging environments, it operates reliably from -20°C to +70°C. For versatile system integration, the module utilizes a 24-pin FPC and primarily supports an SPI interface, with options for MCU, RGB, LVDS, and others upon customization. Its compact dimensions (105.5x67.2x4.75mm) and high brightness (standard 800 cd/m²) make it an ideal solution for space-constrained, high-visibility applications.

Features:

The CH430WQ22A-CT distinguishes itself through a combination of robust specifications and adaptable design:

• Optimized Compact Form Factor: With a module size of 105.5x67.2mm and a slim 4.75mm profile, it maximizes display area (95.04x53.86mm active area) within a minimal footprint, perfect for portable and embedded devices.

• Clarity and Color Performance: The 800x480 WVGA resolution provides sufficient detail for complex interfaces, while the 16M-color depth and 800:1 contrast ratio ensure rich, true-to-life imagery.

• Superior Visibility: The IPS technology guarantees consistent color and clarity across an ultra-wide 80-degree viewing cone in all directions. A high-brightness 800 cd/m² backlight (customizable up to 1500 cd/m²) ensures readability even in direct sunlight.

• Versatile Connectivity: While default configured with an SPI interface on a 24-pin FPC, its architecture supports easy adaptation to MCU, RGB, or LVDS protocols, offering significant flexibility for diverse hardware platforms.

• Environmental Resilience: Engineered for reliability, it supports an extended operating temperature range (-20°C to +70°C) and storage conditions down to -30°C, making it suitable for both indoor and outdoor applications.

• Modern Touch Interface: The inclusion of a projected capacitive touch panel (PCAP) with IIC communication provides a durable, multi-touch capable solution resistant to surface wear, outperforming traditional resistive touchscreens.

Technical Parameters:

Customization:

At Chenghao Optoelectronic, we understand that standard modules may not fit every unique application. The CH430WQ22A-CT serves as an excellent platform for extensive customization to meet your exact specifications. Our flexible customization process includes:

(1) Interface & FPC Tailoring: Choose the optimal interface (SPI, MCU, RGB, MIPI, LVDS, EDP, HDMI) for your system's mainboard. We can customize the FPC's shape, length, stiffness, and pinout (beyond the standard 24-pin) to fit your mechanical design and connection needs.

(2) Optical & Environmental Tuning: Adjust the backlight brightness from a standard range (300-1000 cd/m²) up to 2800 cd/m² for sunlight readability. We can apply anti-glare (AG) or anti-reflection (AR) coatings. Operating temperature can be tailored for commercial (0~50°C), industrial (-20~70°C), or extreme environments (-45~90°C).

(3) Mechanical & Touch Modifications: Customize the cover glass shape, thickness, and add openings or silk-screen printing (logos, icons). You can opt for different touch solutions: keep the capacitive touch, switch to resistive touch for stylus input, or order a display-only version without a touch panel.

(4) Enhanced Reliability Features: Add EMI shielding or strengthened bonding to ensure stable operation in electrically noisy environments.
Our engineering team collaborates with you from concept to production, ensuring your customized CH430WQ22A-CT variant integrates seamlessly and performs reliably.
