1080*1920 Dot Matrix Lcd Display Module 5.5" Wide View Ltps Tft Lcd Screen

Product Description

1080*1920 Dot Matrix Lcd Display Module 5.5" Wide View Ltps Tft Lcd Screen

1. Specification

2. Description


CHENGHAO Display CH550FH02A is a High Brightness color LCD screen, using MIPI interface, the brightness is 600 cd/m2, and it supports sunlight readability. There is a 5.5 inch active area of this tft lcd screen modules with a resolution of 1080*1920, which can display 16M colors and support IPS full viewing angle (80/80/80/80). The 5.5 inch full HD tft display can operate normally in the environment of -20~+70 ℃, and the average service life exceeds 20000 H. It can be modified according to customer requirements, such as FPC shape structure design, interface customization, brightness modification, etc.
CH550FH02A is a full high-definition color LCD screen used in face recognition equipment. It has CE and RoHS certificates that meet European and American standards, and can provide at least one year of warranty service according to the customer's purchase quantity. It is worth mentioning that we also have many 5.5 inch color LCD modules similar to CH550FH02 for you to choose from. You can get relevant information by consulting our 24-hour online customer service. Of course, as a comprehensive enterprise focusing on the production and sales of LCD screens, Chenghao Display can undertake all kinds of customized services about LCD screens for you. We look forward to your reply!

3. Quick Detail


Lcm Name: 1080*1920 Dot Matrix Lcd Display Module 5.5" Wide View Ltps Tft Lcd Screen

Lcm No. CH550FH02A

Supplier Name: Chenghao Optoelectronic

Supplier Type: LCD Manufacture

Lcm Type: 5.5 inch TFT

Lcm Mode:LTPS/Normally Black

Resolution:1080*1920 dots

Lcm Size  70.14*127.6*1.6 mm

Active area: 68.04*120.96 mm

Tft Interface: MIPI

Viewing Direction: 85/85/85/85

Luminance:600 cd/m2

FPC : 25pin

Color: 16.7M

Operating Temp: -20~ +70

Storage Temp: -30~ +80
