4.41 Inch FHD TFT Display 1920x1080 Resolution Sunlight Readable LCD Display

Minimum Order Quantity : 1PCS Price : Negotiation
Packaging Details : All the products are packed in right way to keep it safe. For small sizes of products we use tray + carton, For bigger sizes we use foam slot + carton. we also design packages according to customers' requirements Delivery Time : 7-15 working days
Payment Terms : T/T Supply Ability : 300Kpcs/month
Place of Origin: ShenZhen, China Brand Name: Chenghao/Oem
Certification: ROHS、ISO9001、CE Model Number: CH441FH01A

Detail Information

Product Name: 4.41 Inch FHD TFT Display OUTLINE DIMEMSIONS: 106.7(W ) X66.1(H) X2.8(T) Mm
ACTIVE AREA: 97.63(W) X54.92(H) Mm PIXEL ARRANGEMENT: RGB VERTICAL STRIPE
NUMBER OF DOTS: 1920 X RGB X1080 Dots DOT PITCH: ----
VIEWING DIRECTION: ALL DRIVER IC: ----
High Light:

4.41 Inch FHD TFT Display

,

Sunlight Readable FHD TFT Display

,

1920x1080 Sunlight Readable LCD Display

Product Description

4.41 Inch FHD TFT Display 1920x1080 Resolution Sunlight Readable



1. Specification



ITEM STANDARD VALUES UNITS
LCD type 4.41 inch tft --
Dot arrangement 1920x1080 dots
Driver IC ****** --
Module size

106.7(W ) x66.1(H) x2.8(T)
mm
Active area
97.63(W) x54.92(H)
mm
Dot pitch *** mm
Operating temperature - 20 ~ + 70
Storage temperature - 30 ~ + 80
Back Light  White LED --
Weight TBD g


2. Description


Chenghao Optoelectronic CH441FH01A is a small size full HD color LCD screen, including an lcd panel, a driver IC, a backlight and FPC and other components.

This lcd panel (horizontal screen) is of TFT type and has a 4.41 inch 1920x1080 resolution FHD color display area that supports IPS all viewing directions.

The driver IC is attached to the glass panel, supports LVDS interface, and is interconnected with other components through FPC. After inputting RGB signal, the driver IC can drive the FHD tft display to display 16M colors.

The back light assembly contains 12 pcs white leds that can produce a Luminance of over 1000 cd/m2, making the 4.41 inch ips tft display sunlight readable.

In addition, the 4.41 inch FHD tft lcd can be modified according to customer requirements, the modified content includes installing touch function, modifying BL, designing FPC shape structure, defining interface and so on.

If the CH441FH01A cannot meet your requirements, we can also provide you with other display solutions, and at the same time, we can also provide customized services for your project.



You can get in touch with us through instant online customer service or email, we look forward to cooperating with you.




4.41 Inch FHD TFT Display 1920x1080 Resolution Sunlight Readable LCD Display 0



3. Drawing


4.41 Inch FHD TFT Display 1920x1080 Resolution Sunlight Readable LCD Display 1










4. Quick Detail


Diagonal Display Size: 4.41 inch

Interface Type: LVDS

Resolution: 1920x1080 pixels

With / Without Touch Screen: without

Active Area Dimensions:97.63(W) x54.92(H) mm

Supply Voltage: 3.3 V

Backlight Type: White LED

Display Mode: Transmissive/ Normally Black

Dimensions: 106.7(W ) x66.1(H) x2.8(T) mm

Display Matrix Technology: TFT

Minimum Operating Temperature: -20°C

Maximum Operating Temperature: +70°C

Brightness: >1000 cd/m²

Number of Colours: 16.7 Million

Standards Met: CE, RoHS Compliant

Response Time: ***

Operating Temperature Range: -20 → +70°C

Voltage Rating: 3.3V

Contrast Ratio:800

Display Type: 4.41 inch tft





5. Application


4.41 Inch FHD TFT Display 1920x1080 Resolution Sunlight Readable LCD Display 2





6. FAQ


Q:Payment methods?

T/T, Paypal and Western union etc.

For samples: payment in advance.

For mass production: 50% deposit and 50% balance before shipment.



Q: What is the lead time of the products?

A:Samples in stock will be sent within 3 days after payment.

Two to Four weeks for mass production



Q:How long is the warranty period?

A:Generally the warranty period is one year. It depends on different products.



Q:What is the Product MOQ?

A:Different product has the different MOQ, please contact us sales for detailed information.



Q: What's your after-sale service?

A: If any problems, you will get our reply within 24 hours. Solution will be offered instantly by our professional technical team.



Q:Can you provide OEM service?

A:yes, we can provide both OEM and ODM service,can customize products according to the drawings you supply



Q: How can I trust your product quality?



A:The company has advanced the incoming inspection,    on-line test and reliability test equipment and system, the company products through the ROHS,CE testing
