240x320 Tn TFT LCD Module 2.2" Transmissive TN FPC SPI With ILI9341V IC

Minimum Order Quantity : 1PCS Price : /
Packaging Details : All the products are packed in right way to keep it safe. For small sizes of products we use tray + carton, For bigger sizes we use foam slot + carton. we also design packages according to customers' requirements Delivery Time : 7-15 working days
Payment Terms : T/T Supply Ability : 300Kpcs/month
Place of Origin: ShenZhen, China Brand Name: Chenghao/Oem
Certification: ROHS、ISO9001、CE Model Number: CH220QV06A

Detail Information

Product Name: 8 Bit Lcd Display Resolution: 240x320
Color: 262K / 65K / 16.7M Display Mode: Normally White TN,Transmissive
Connection: Connector Pin Number: 14
High Light:

240x320 Tn TFT LCD Module

,

Transmissive TN TFT LCD Module

,

FPC SPI Lcd Display Module

Product Description





1. Specification



Type: 2.2"TFT
Viewing Direction:  6 o' Clock
Connection type: COG + FPC
Operating temperature: -20℃~70℃
Storage temperature: -30℃~80℃
Driver IC: ILI9488
Interface type: 4-lines_8bit SPI

Brightness:

250CD/m2



2. Description





ChengHao Display model CH220QV06A is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This model is composed of a TFT LCD panel, a driving IC, a back-light, and FPC.

This TFT LCD has a 2.2  ( vertical screen ) inch diagonally measured active display area with 240 horizontal by 320 vertical pixel .

The driver used for this project is the ILI9341V and can display 262K colors by 8 bit SPI signal input. The driver is mounted on the glass and the interconnection via FPC including components to drive the display module. Support SPI interface.

In addition, FPC can also be customized according to customer requirements, such as modifying back-light and CTP structure, interface definition, etc.

RoHS Compliance & Halogen Free.



3. Drawings



Notes:
(1) Display Type : 2.2 inch TFT + RTP
(2) Viewing Direction : 6:00
(3) Lcd Drive IC : ILI9341V
(4) Polarizer Mode : Transmissive/ Positive
(5) Operating Temp : -20~70 ℃
(6) Storage Temp : -30~80 ℃
(7) Unmarker Tolerance: ±0.20
(8) Protection : ROHS

240x320 Tn TFT LCD Module 2.2" Transmissive TN FPC SPI With ILI9341V IC 0





4. Quick Detail





* LCD name: Wholesale 2.2" 8 Bit Lcd Display 240x320 Resolution Tn Tft Module  With ILI9341V IC
* Part No. : CH220QV06A
* Size.: 2.2 inch
* With touch panel or not: No
* Support Touch type: Capacitive |Or Resistive Touch Panel
* Display type: 2.2"TFT
* Display colors: 262K (option 16.7M / 65K )
* Resolution (pixels): 240(RGB)*320
* Pixel pitch: 0.219 (H)*0.219(V) mm
* Viewing direction: 6:00
* Controller IC: ILI9341V
* Display mode: Transmissive/ Normally White/TN
* Overall size: 40.1(W)×55.2(H)×2.35(T) mm
* Active Area: 33.84(W)×45.12(H) mm
* Luminance: 250 cd/m2
* Contrast: 500 : 1
* Interface type: 4 lines 8 Bits SPI ( Optionl RGB / MCU / MIPI Interface )
* Pin NO.: 14pins
* Pin pitch: 0.4 mm
* Connecting type: Connector type
* Input voltage: 3.2 V
* Backlight type and color: LED backlight/white
  Backlight: 4 LED parallel
* LED Life span: 20000h






5. Application



* Products are widely used in general communications, household appliances, industrial control, medical



equipment, POS machines, instrumentation, GPS navigation, digital photo frames, netbooks, financial



electronics, communication electronics, consumer electronics, information appliances, culture, education,



sports and entertainment and other fields .



* Such as smart wearable devices (such as watches, fingertip pulse meters), car display devices (car central



control display, navigation display/headrest display, etc.), payment financial equipment (card reader, cash



register, etc.), customer terminal equipment (refrigerator, Coffee machine, smart rice cooker, etc.), elevator



display equipment (elevator digital display), industrial control equipment (industrial display), instrument



measuring equipment (detector, monitor), artificial intelligence equipment (smart robot), medical equipment



(heart rate monitoring display) ), smart home equipment (kitchen smoke machine), security identification



equipment (smart access control, punch card machine, etc.), vending equipment (vending machine), etc.
