320*240 Pixel LCD Display Module 3.5 Inch TFT Display Replacement

Minimum Order Quantity : 2 PCS Price : /
Packaging Details : All the products are packed in right way to keep it safe. For small sizes of products we use tray + carton, For bigger sizes we use foam slot + carton. we also design packages according to customers' requirements Delivery Time : 7 - 15 working days
Payment Terms : T/T Supply Ability : 200K PCS / Month
Place of Origin: ShenZhen , China Brand Name: OEM
Certification: ROHS 、ISO9001 、CE Model Number: CH350QV06A

Detail Information

Product Name: 3.5 TFT Display LCD TYPE: TRANSMISSIVE
DISPLAY TYPE: DISPLAY TYPE LCD COLOR: 16.7M / 165K / 262K
VIEWING ANGLE: -20° C ~ +70° C STORAGE TEMP: -30° C ~ +80° C
BACKLIGHT TYPE: WHITE LED
High Light:

320*240 Pixel LCD Display Module

,

3.5Inch LCD Display Module

,

3.5 Inch TFT Display

Product Description

320*240 Pixel LCD Display Module 3.5 Inch TFT Display Replacement



1. Specification of 3.5 inch TFT Display

LCD TYPE TFT
POLARIZER TYPE TRANSMISSIVE
DISPLAY TYPE POSITIVE
LCD COLOR 16.7M/165K/262K
VIEWING ANGLE 6:00
OPERATING TEMP -20°C ~ +70°C
STORAGE TEMP -30°C ~ +80°C
BACKLIGHT TYPE WHITE LED
CONTROLLER IC HX8238D



2. Description of 3.5 inch TFT Dispay

-ChengHao Display model CH350QV06A is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This model is composed of a TFT LCD panel, a driving IC, a back-light and FPC.

-This TFT LCD has a 3.5 (Square screen) inch diagonally measured active display area with 320 horizontal by 240 vertical pixel.

-The driver used for this project is the HX823BD and can display 16M / 65K / 262K (Optional) colors by R.G.B. signal input. The driver is mounted on the glass and the interconnection via FPC including components to drive the display module. Support RGB interface.

-In addition, FPC can also be customized according to customer requirements, such as modifying back-light and CTP structure, interface definition, etc.

-RoHS Compliance & Halogen Free.


3. Quick Detail of 3.5 inch TFT Display

*LCD name: Custom 3.5 TFT Display 320*240 Pixel Positive Replacement Lcd Clear Screen
* Part No.: CH350QV06A
* Size.: 3.5 inch
* With touch panel or not: NO
* Display type: TFT
* Display colors: 16.7M/262K/165K
* Resolution (pixels): 320(RGB)*240
* Viewing direction: 6:00
* Controller IC: HX8238D
* Display mode: Transmissive/ Normally White
* Overall size: 76.9(W)*63.9(H)*3.3(T) mm
* Viewing area: 71.350(W)*53.900(H)mm
* Active Area: 70.08*52.56 mm
* Luminance: 300 cd/m2
* Interface type: SPI/(SPI+RGB)/MCU (optional)
* Pin NO: 50pins
* Connecting type: plugging type
* Backlight type and color: LED backlight/white
* LED Life span: 50000h



4. Drawings of 3.5 inch TFT Display

Notes:
(1) Display Type : 3.5" TFT
(2) Viewing Direction : 6:00
(3) Lcd Drive IC : HX8238D
(4) Operating Temp : -20~70 ℃
(5) Storage Temp : -30~80 ℃
(6) Unmarker Tolerance: ±0.20
(7) Protection : ROHS

320*240 Pixel LCD Display Module 3.5 Inch TFT Display Replacement 0






5. Application of 3.5 inch TFT Display
3.5 TFT Display Screens,widely used in medical,communication,instruments and other Application.

320*240 Pixel LCD Display Module 3.5 Inch TFT Display Replacement 1

6. Our Service

1.We provide one-year product after-sales guarantee service to all customers who purchase our products.
2. For any technical problems encountered by customers in the process of testing or using our products, our technical team will provide customers with remote online technical support services at any time.
3. We are a factory-type supplier with ISO certification. Our products on sale have undergone strict quality inspection and testing before shipment, and have also passed CE/ROHS certification.
4. We have a professional after-sales service team, which can provide strong guarantee and logistical technical services for your orders.
5. Replacement within 30 days after the shipment of products from us due to products' problems.
6. We have long cooperation with many shipping companies and our export volume is large. The shipping companies can offer us good discounts.
7. All goods will be inspected and tested before shipment.
8. Customer`s satisfactory is most important to us.If you have any problem or questions regarding our transaction.Please contact us by Email. It will be responded within 24 hours.

7. Why Choose Us ?
 The high quality products enable it to build a long-term relationship with world-famous enterprises in the industries
(1) Competitive Price
Own-owned factories offer lower prices and better quality assurance.
(2) Strong Technical Strength
We are a top supplier specializing in the production of color LCD screens. We have a technical team with rich experience in product research and development, and can provide customers with professional technical support and customized consulting services at any time, which is very important for cooperative customers with special project needs.
(3) Long-term Partner
Products are sold to more than 40 countries, so from Chenghao Optoelectronic you can get more stable supplying promise;
(4) Professional Service
We have a professional after-sales team that can provide you with after-sales consulting services 24 hours a day.At the same time, if you encounter any problems in the process of using our products, you can give us feedback, and our technical engineers will provide you with online remote consulting services at any time.
(5) Quality to be ensure
All panels are 100% brand new, without false panels; All packages have labels and serial numbers for easy viewing by customers;


8. FAQ



Q: How can i find the right product?
A: Please send us your requirements, we will recommend our standard products, if it’s not fit, we will do the necessary adjustment & customization.

Q: How to customize the product?
A: Customized procedures goes like this: Project scope clarification → Fill Requirement Form → Engineering analysis → Cost→Evaluation → Customer confirmation → Providing drawing → Customer confirmation → Sampling → Customer approval → Mass production

Q: Do you accept sample order or small quantity order?
A: Yes, you can place sample orders for testing first, and small quantity order as pilot production (no less than MOQ)

Q: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.

Q: What’s the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and 4~5 weeks for mass production (basing on the quantity and product)
