5 Inch IPS TFT LCD Display Module 1024x600 LVDS 500 Nits for Industrial HMI

Product Description

The CH500WS01A is a 5.0 inch IPS TFT LCD display module with a 1024 x (RGB) x 600 resolution and a 40-pin LVDS interface. It delivers a typical brightness of 500 cd/m2, 16.7 million colors, and an 85/85/85/85 viewing direction for consistent readability from multiple positions. The panel uses an IPS transmissive normally black mode with a 120.7 x 75.8 mm outline and a 108.03 x 64.8 mm active area. Operating temperature ranges from -20 to +70 degrees Celsius, while storage temperature ranges from -30 to +80 degrees Celsius. The module has no touch panel and is designed for industrial HMI panels, instrumentation, control terminals, and embedded display systems that require a stable LVDS interface and long-term supply.

Product Features

• 1024 x (RGB) x 600 resolution provides sharp text, graphs, and operator interface content.
• 500 cd/m2 typical brightness supports clear viewing in most indoor and controlled industrial environments.
• IPS technology with an 85/85/85/85 viewing direction maintains image consistency from every side.
• A 40-pin LVDS interface simplifies integration with industrial control boards and display controller platforms.

Product Drawing

Detailed Specifications

Customized Introduction

Chenghao provides customized display module services for TFT LCD modules, mono LCD displays, color OLED modules, and mono OLED modules. Customization covers FPC layout and pin configuration, interface selection, brightness tuning, touch integration, anti-glare surface treatment, and cover glass design.

• FPC customization includes outline, length, pin count, and connector layout.
• Interface options include LVDS, SPI, MCU, RGB, MIPI, EDP, and HDMI.
• Brightness can be tuned for standard indoor use or higher ambient-light environments.
• Capacitive touch, resistive touch, and no-touch configurations are available.
• AG surface treatment can reduce reflections in bright installation areas.
• Cover glass can be customized by thickness, shape, color, and silk printing.

Application Cases

• Industrial HMI Panels: The 1024 x 600 resolution and LVDS interface support clear operator dashboards, machine status screens, and control terminals.
• Test and Measurement Equipment: Wide viewing angles and stable color output help technicians read waveforms, values, and menus from different positions.
• Kiosk and Control Terminals: The compact 5.0 inch outline and 40-pin interface simplify integration into space-constrained embedded systems.
• Building Control Equipment: A 500 cd/m2 display and wide temperature range support dependable operation in monitored indoor environments.
