15.6 Inch Display Module 12 O'clock Viewing Direction TN Tft Screen

Product Description:

The CH156FH02A is a high-performance 15.6-inch TFT display module meticulously crafted by Chenghao Optoelectronics. This module boasts a resolution of 1920*1080 pixels, 16 million colors, and a 500:1 contrast ratio, delivering vivid and clear visuals suitable for various professional applications. Utilizing TN/transmissive/normal white display modes and a 12 o'clock viewing angle design, the module offers a wide viewing angle and uniform brightness distribution. Its 300 cd/m² backlight brightness meets standard usage requirements, while also supporting customized brightness up to 3500 cd/m² to suit special scenarios.

The module measures 370 x 2179.3 mm, with an effective display area of ​​344 x 193 mm, achieving a good balance between compact design and ample display space. This module supports extensive customization services to meet the specific needs of various industries, including customized FPC shape, structure, and pin count; multiple interface options (SPI, MCU, RGB, etc.); adjustable operating temperature (-10~+60℃ to -45~+90℃); glass cover modification; and optional touch functionality integration.   Furthermore, additional features such as anti-glare treatment and electromagnetic interference resistance further expand its application range in professional fields such as industrial control, medical equipment, and automotive displays.

Features:

• High-Resolution Clear Display

This display module features a 1920*1080 Full HD resolution, capable of outputting 16M colors, meeting the high-definition display needs of various application scenarios.

• Flexible Screen Brightness Selection

The module comes standard with a screen brightness of 300 cd/m², satisfying the visual needs of most general scenarios. In addition to the standard configuration, it also offers rich brightness customization capabilities, allowing for flexible adjustment between 300 cd/m² and 3500 cd/m². This flexibility enables it to adapt to diverse lighting environments, ensuring clear visibility whether in dimly lit indoor spaces requiring soft brightness or in bright outdoor environments needing higher brightness to combat glare.

• Wide Temperature Adaptability

The CH156FH02A boasts a robust temperature resistance design, with an operating temperature range of -20℃ to +70℃ and a storage temperature range of -30℃ to +80℃. This wide temperature adaptability enables the module to work stably in harsh environmental conditions, resisting the adverse effects of extreme cold or high temperature, eliminating concerns about performance degradation due to temperature fluctuations, and making it suitable for application scenarios with unstable or extreme temperatures.

Technical Parameters:

Customization:

The CH156FH02A is a 15.6-inch TFT LCD module launched by Shenzhen Chenghao Optoelectronics Co., Ltd. Leveraging the manufacturer's professional expertise in TFT LCD technology and standardized customization processes, it offers comprehensive and flexible customization services to meet the diverse needs of various industrial and professional scenarios.

In terms of hardware and structural customization, the flexible printed circuit board (FPC) customization goes beyond basic shape and pin count adjustments. Based on the module's 12V power supply configuration, the FPC pin definitions can be customized according to the customer's system power supply requirements, ensuring seamless compatibility with host devices. Furthermore, the default maximum screw depth of 5.0 mm is adjustable—customers can specify shorter or optimized depth parameters and hole layouts according to their own mounting fixture requirements, improving assembly efficiency.

Optical performance customization is highly flexible. The default transmissive/positive polarizer mode can be adjusted according to specific visual needs, and the standard 12 o'clock viewing direction can also be customized to other orientations, ensuring optimal viewing effects in scenarios with fixed viewing angles. The screen brightness starts at a standard 300 cd/m² and can be calibrated within a range of 300 cd/m² to 3500 cd/m². Precise adjustment of brightness uniformity is also possible to suit dimly lit indoor environments or brightly lit outdoor scenarios.

Environmental adaptability and compliance customization further expand the module's application range. The product itself complies with RoHS environmental standards and can be upgraded to more stringent environmental regulations based on different regional or industry requirements. The operating temperature range (-20℃ to +70℃) and storage temperature range (-30℃ to +80℃) can be extended to a wide temperature range of -45℃ to +90℃ through material and component optimization, ensuring stable operation in extreme low or high temperature environments. Furthermore, professional shielding design enhances electromagnetic interference (EMI) immunity to adapt to complex electromagnetic environments.

Structural and surface customization includes glass cover modification: customers can customize the cover's shape, thickness, and opening position, and add industry-specific silkscreen markings, symbols, or light-shielding patterns. The anti-glare level is also adjustable – from mild anti-glare to meet clear imaging needs, to high anti-glare for strong light environments, without affecting display clarity. In terms of functionality, in addition to optional capacitive or resistive touch, touch sensitivity can be calibrated according to specific application scenarios. Interface customization supports multiple protocols besides LVDS, including SPI, MCU, and RGB, and data transmission parameters can be optimized for specific application transmission rate requirements.
