15.6" Large Display Screen 30pins -20 +70 Wide-temp LVDS Display Module

Product Description:

The CH156FH02A is a 15.6-inch TFT LCD module engineered for clarity, reliability, and adaptability in demanding visual environments. Featuring a native Full HD resolution of 1920×1080, it renders sharp, detailed imagery with support for 16.7 million colors, ensuring vibrant and accurate color reproduction. Built on a TN (Twisted Nematic) transmissive architecture with a normally white mode, the panel delivers fast pixel response and consistent luminance across its 344×193 mm active area. A standard brightness of 300 cd/m² and a contrast ratio of 500:1 provide clear visibility under typical indoor ambient lighting.

This module utilizes an LVDS interface via a 30-pin flexible printed circuit, enabling efficient high-speed data transmission with low electromagnetic emission—ideal for noise-sensitive installations. While delivered without integrated touch functionality, the design accommodates optional capacitive or resistive touch overlays during production, allowing seamless adaptation to interactive use cases. The CH156FH02A operates reliably across a broad temperature range of –20°C to +70°C and can be stored in conditions from –30°C to +80°C, demonstrating resilience in fluctuating thermal environments.

As part of Chenghao Optoelectronic’s modular customization strategy, the CH156FH02A serves as a foundational platform that can be enhanced with tailored backlighting, extended temperature tolerance, anti-glare coatings, EMI shielding, and bespoke mechanical or optical configurations. Its balanced blend of performance, ruggedness, and flexibility makes it well-suited for control systems, diagnostic equipment, automation interfaces, and other professional-grade applications where visual fidelity and long-term stability are critical.

Technical Parameters:

Features:

• True Full HD 1920×1080 Resolution for Precision Imaging
  The CH156FH02A delivers native 1920×1080 pixel resolution, enabling high pixel density across its 15.6-inch active area. This level of definition ensures fine detail reproduction and sharp text rendering—essential for applications requiring accurate visual data interpretation, such as monitoring interfaces or technical visualization systems where clarity directly impacts operational efficiency.

• Robust LVDS Interface for Noise-Resilient Signal Integrity
  Leveraging a 30-pin LVDS (Low-Voltage Differential Signaling) interface, the module transmits video data with minimal latency and excellent immunity to electrical interference. This differential signaling method reduces crosstalk and power consumption while maintaining stable image quality over extended cable lengths, making it ideal for integration into electromagnetically complex or industrial-grade setups.

• Wide-Temperature Operation from –20°C to +70°C for Environmental Reliability
  Engineered to function continuously across a –20°C to +70°C operating range, the CH156FH02A is well-suited for non-climate-controlled environments. This wide-temp capability ensures consistent startup, image stability, and long-term performance in settings such as transportation interiors, field-deployed instrumentation, or enclosed enclosures subject to solar heating or seasonal temperature swings.
