3.5" CTP Industrial Capacitive Touch Screen 320x480 300cd/m2 TFT LCD Display Module
Contact Person : Tina Fu
Phone Number : +86 755-27806536
WhatsApp : +8615919862398
| Minimum Order Quantity : | No Moq | Packaging Details : | All the products are packed in right way to keep it safe. For small sizes of products we use tray + carton, For bigger sizes we use foam slot + carton. we also design packages according to customers' requirements |
|---|---|---|---|
| Delivery Time : | 3~7 Days | Payment Terms : | TT or Others |
| Supply Ability : | 20000000 pcs/month |
| Place of Origin: | China，Shenzhen | Brand Name: | Chenghao Optoelectronic |
|---|---|---|---|
| Certification: | CE 、RoHS、FCC | Model Number: | CH800WX04A-CT |
|
Detail Information |
|||
| Product Name: | Lcd Monitor Touchscreen | Touch Glass Cover Lens: | 0.7 Mm |
|---|---|---|---|
| Capacitive Touch Panel Driver IC: | GT911 | Display Mode: | Transmissive / IPS / Normally Black |
| Viewing Angle: | 85/85/85/85 | Color Saturation: | 16 M |
| Module Outline Size: | 203.4*14.94*6.4 Mm | Operating Temperature: | -30 ~ +85 ℃ |
| Display Type: | 8”TFT + CTP | ||
| High Light: | LCD Monitor Touchscreen 1280x720,LCD Monitor Touchscreen With 30Pins FPC |
||
Product Description
The TFT LCD Capacitive Touchscreen is a high-quality display module that combines the features of a touch LCD screen and a TFT LCD module. This innovative product offers advanced touch capabilities and vibrant display, making it ideal for a wide range of applications in the consumer electronics industry.
| Parameter | Numerical Value |
|---|---|
| Module Size | 203.4*149.4*6.4 mm |
| Viewing Area | 177.24*99.96 mm |
| Active Area | 176.64*99.36 mm |
The Touch Glass Cover of the TFT LCD Capacitive Touchscreen is made of high-quality materials to ensure durability and smooth touch operation. It also offers a high transmittance rate of at least 87% for clear and vivid display.
The viewing area of the TFT LCD Capacitive Touchscreen is 177.24*99.96 mm, providing a larger and wider display compared to traditional LCD screens. This allows for more detailed and realistic visuals, making it perfect for gaming, video streaming, and other multimedia applications.
The touch panel of the TFT LCD Capacitive Touchscreen operates at a voltage range of 2.8V~3.3V, making it energy-efficient and suitable for battery-powered devices. This also helps to prolong the lifespan of the product, making it a cost-effective option for businesses.
The Touch Glass Cover of the TFT LCD Capacitive Touchscreen has a hardness rating of 6H, providing excellent resistance against scratches and damage. This makes it suitable for use in rugged environments and ensures long-lasting performance.
CH700WV09B-CTB-PI has the following features:
High resolution and color saturation: CH700WV09B-CTB-PI has a resolution of 1280x720 and 16M color saturation, which can present clear and detailed images and rich and vivid colors.
IPS display technology: This display module adopts IPS display technology, which enables a wider viewing angle and users can obtain clear visual effects from different angles.
Capacitive touch screen: CH700WV09B-CTB-PI is equipped with a capacitive touch screen that supports human-computer interaction, allowing users to operate and control display content through touch.
High-brightness backlight: This module uses high-brightness white LED backlight components, which can produce a maximum brightness of 1200 cd/m2, so that the display content is still clearly visible in the sun, making it suitable for outdoor applications.
Anti-glare technology: The surface of CH700WV09B-CTB-PI adopts anti-glare technology, which greatly improves the reading experience in outdoor environments and reduces the interference of light reflection on the user's vision.
Wide temperature design: This module has a wide temperature range design and can work normally in the temperature range of -30°C to +85°C.
Customized services: Chenghao Optoelectronic provides a wealth of customized services, including module customization, packaging customization and transportation customization, to meet customers' individual needs.
In short, CH700WV09B-CTB-PI features high resolution, IPS display technology, capacitive touch screen, high-brightness backlight and anti-glare technology. It is suitable for various application scenarios and can be customized according to customer needs. If you have project needs for LCD/LCM/LCD solutions, Chenghao Optoelectronic will provide you with high-quality products and customized services.
View source
| LCD Display Module | Touch TFT Displays |
|---|---|
| Brightness | 1200 Cd/m2 (Can Be Modified According To Customer Requirements) |
| Resolution | 1280*720 Dots |
| Storage Temperature | -40 ~ +90℃ |
| Warranty | 12 Months |
| Operating Temperature | -30 ~ +85 ℃ |
| Touch Glass Cover Transmittance | ≥ 87% |
| Touch Panel Interface | I2C |
| Viewing Area | 177.24*99.96 Mm |
| Display Type | 8”TFT + CTP |
| Active Area | 176.64*99.36 Mm |
Consumer electronics field: CH700WV09B-CTB-PI can be applied to various consumer electronics products, such as GPS navigation, digital photo frames, notebook computers, etc.
Automotive equipment field: This display module is suitable for vehicle display equipment, such as vehicle central control display, navigation display and headrest display, etc., providing high-quality display solutions for automobile manufacturers and car owners.
Financial payment equipment field: CH700WV09B-CTB-PI can be used in financial payment equipment, such as POS machines, card readers and cash registers, etc., to provide merchants with safe and efficient payment solutions.
Customer terminal equipment field: This display module is suitable for various customer terminal equipment, such as refrigerators, coffee machines, and smart rice cookers, providing assistance for a convenient and intelligent lifestyle.
Industrial control equipment field: CH700WV09B-CTB-PI is suitable for industrial control equipment, such as industrial displays and instrument equipment.
Medical equipment field: This display module can be applied to medical equipment, such as heart rate monitors and forehead thermometers, to provide advanced monitoring and diagnostic solutions for the medical industry.
Smart home equipment field: CH700WV09B-CTB-PI is suitable for smart home equipment, such as smart coffee machines, smart refrigerators and kitchen range hoods, etc., providing users with an intelligent and convenient home experience.
To sum up, as a multi-functional display module, CH700WV09B-CTB-PI can be used for consumer electronics, automotive equipment, financial payment equipment, customer terminal equipment, industrial control equipment, medical equipment and smart home equipment. Meet the corresponding usage requirements.
CH700WV09B-CTB is a customized display module from our company with the following features and customization options:
Module customization:
FPC customization: We can redesign the shape and structure of the FPC according to the customer's project needs to ensure that it perfectly fits the installation equipment.
Backlight design: We provide backlight components with a maximum brightness of 2800 cd/m2, and customers can choose the appropriate brightness according to actual needs.
Module interface customization: Our display module can define the interface type according to customer requirements. Supported interface types include SPI, MCU, RGB, MIPI, LVDS, HDMI, etc.
Touch solutions: We provide capacitive touch solutions and resistive touch solutions. The core of the capacitive touch solution is to design a glass covering layer that conforms to the application device to meet glass thickness, hardness and other requirements.
Display module specifications:
Resolution: The resolution of CH700WV09B-CTB is 1280x720 pixels.
Viewing angle: Supports 85/85/85/85 free viewing angle.
Size: 8-inch display, module overall size is 203.4*149.4*6.4 mm, viewing area size is 177.24*99.96 mm, effective display area is 176.64*99.36 mm.
Packaging customization:
Our product packaging meets export hardness standards and includes foam padding inside to prevent screen damage.
Our products are packed in large boxes plus small boxes. The weight of each box does not exceed 3.5 kilograms. The size may vary according to standards. We will use pallets or wooden frames to transport the goods.
We provide one-year product after-sales guarantee service to customers who purchase our products.
If you encounter any technical problems during testing or using our products, our technical team will provide remote online technical support services to customers at any time.
We are a factory-type supplier with ISO certification. The products we sell undergo strict quality inspection and testing before shipment, and have also passed CE/ROHS certification.
We have a professional after-sales service team that can provide strong guarantee and logistics technical services for your orders.
Thank you for your attention and support to Chenghao Optoelectronics. If you have any more questions or need further information about the customization services of CH700WV09B-CTB, we will be very happy to help you. Please feel free to contact us. Thanks!
