HDMI Input Signal Thin Film Transistor LCD LED Backlight 3.5 Inch TFT Display

Product Description:

CH350HV37A is a Square Transmissive type color active matrix liquid crystal display (LCD) which is composed of a TFT LCD panel, driver IC, FPC, and backlight.

This LCD module has a resolution of 320x480 and offers various levels of brightness selections from 200 - 600cd/m2. It also comes with/without touch, and is RoHS & REACH compliant.

If you don't find a model that meet your needs, please don't hesitate to get in touch with us and we can provide recommendation.

Features:

• Thin Film Transistor LCD Display
• Brightness of 300cd/m2
• Storage Temperature of -30℃~70℃
• Response Time of 5ms
• Contrast Ratio of 1000:1
• Lifetime of 50,000 Hours

Technical Parameters:

This 3.5-inch TFT display has an array of 320*480 dots and is in the display mode of "TN/Transmission/Normally White". The module size of it is 56.54(W)×84.96(H)×2.4(T), with an active area of 48.96(W)×73.44(H). Its brightness ranges from 300 to 600cd/m², and its interface can be either 4-lines_8bit / 3-lines_9bit SPI 8-/9-/16-/18-bit 8080 System Interface or 16-/18-bit RGB Interface.

Moreover, its operating temperature is from -20℃ to + 70℃, and the storage temperature is from -30℃ to + 80℃.

Applications:

The Thin Film Transistor (TFT) LCD display manufactured by chenghao optoelectronic, model CH350HV37A, is a reliable Liquid Crystal Display screen with numerous applications. The display has been certified with CE, ISO9001, Rose, and SGS standards. It comes with a minimum order quantity of 200 pieces, individual packing in a carton box, and delivery time of 1-3 working days. Payment options are available through T/T, AliPay, or PayPal. The display has an amazing capacity of 100000pcs/day, and has a brightness of 300cd/m2, display colors of 16.7M, lifetime of 50,000 hours, operating humidity of 10%~90%, and contrast ratio of 1000:1.

Support and Services:

Our technical support and services for TFT LCD Display include:

• Product installation and setup guidance
• Troubleshooting and problem-solving assistance
• Software and firmware updates
• Access to customer support forums
• Live chat and phone support
• Replacement parts and accessories
