3.2" 240x320 TFT QVGA LCD Display Screen White LED For Medical Equipment

Minimum Order Quantity : 100 pcs Price : /
Packaging Details : All the products are packed in right way to keep it safe. For small sizes of products we use tray + carton, For bigger sizes we use foam slot + carton. we also design packages according to customers' requirements Delivery Time : 7-15 working days
Payment Terms : T/T Supply Ability : 300Kpcs/month
Place of Origin: ShenZhen, China Brand Name: Chenghao/Oem
Certification: ROHS、ISO9001、CE Model Number: CH320QV18A

Detail Information

Module Size: 55.04*77.7*2.45 Mm Active Area: 48.6(W)×64.8(H) Mm
Operating Temperature: -20 ~ +70 ℃ Back Light: White LED
Viewing Direction: 80/80/80/80 Dot Arrangement: 240×320
Storage Temperature: -30 ~ +80 ℃
High Light:

Medical Equipment TFT LCD Screen

,

QVGA TFT LCD Screen

,

ST7789 IC QVGA LCD Display

Product Description

3.2" 240x320 TFT QVGA LCD Display Screen White LED For Medical Equipment



Specification of Small LCD Display Screens



Module No CH320QV18A
LCD Type 3.2" TFT
Number of dots 240(RGB)*320
Display Mode IPS/Transmissive/Normally Black
Viewing Direction 80/80/80/80
Display Area 49.4*65.6 mm
Active Area 48.6*64.8 mm
Operating Temp -20~+70 ℃
Lcd Driver IC ST7789
Module Size 55.04*77.7*2.45 mm
Storage Temp -30~+80 ℃


Describe of LCD Display Screens3.2" 240x320 TFT QVGA LCD Display Screen White LED For Medical Equipment 0



Introducing the CH320QV18A Small TFT LCD Display, a reliable and versatile display solution for a range of applications. With a resolution of 240x320 dots and a viewing direction of 80/80/80/80, this module provides clear and vibrant images for laboratory equipment, medical equipment, digital equipment, and more.

The CH320QV18A features an IPS/Transmissive/Normally Black display type, ensuring that your visual information is displayed accurately and clearly. The module has a compact design, the module size is 55.0477.72.45mm, and the display area is 48.6*64.8mm, which is very suitable for installation in small electronic devices.

This TFT LCD Display supports multiple interfaces, including SPI, RGB, and MCU, and has 10 FPC pins, ensuring seamless integration into your equipment.



3.2" 240x320 TFT QVGA LCD Display Screen White LED For Medical Equipment 1

The CH320QV18A is designed to operate in a wide temperature range, from -20℃ to +70℃, making it suitable for use in various environments.



With a life span of 30,000 hours, this module is built to last, providing reliable and consistent performance for your equipment needs. The CH320QV18A is RoHS, CE, and FCC certified, ensuring that it meets international safety and environmental standards.



As a cross-border e-commerce operator, we are proud to offer this high-quality Small TFT LCD Display to our customers, providing a reliable and versatile display solution for a range of applications.













Features of LCD Screen Panel

Support Free View Direction:
The CH320QV18A Small TFT LCD Display features an IPS display type, which allows for a free view experience. This means that the display can be viewed from any angle without any distortion or color shift, making it ideal for applications where multiple viewers need to see the display at the same time. With its free view capabilities, the CH320QV18A offers a flexible and user-friendly experience, making it suitable for applications such as digital equipment, laboratory equipment, and more.

Support Wide Temperature Environment:
The CH320QV18A Small TFT LCD Display is designed to support a wide temperature range, from -20℃ to +70℃. This feature makes it ideal for use in harsh or extreme environments, where temperature variances can be a challenge. With its ability to operate in a wide temperature range, the CH320QV18A ensures reliable and consistent performance, regardless of the conditions it is subjected to. This makes it an ideal choice for applications such as outdoor equipment, automotive displays, and more.

Support Customization on Demand:
The CH320QV18A Small TFT LCD Display can be customized on demand, making it a highly versatile and adaptable solution for a range of applications. Whether you need a specific size, shape, or interface, the CH320QV18A can be tailored to meet your unique requirements. This customizability makes it an ideal choice for equipment manufacturers and designers who need a display solution that can be tailored to their specific needs. With its ability to be customized on demand, the CH320QV18A provides a flexible and scalable solution for a range of applications.

3.2" 240x320 TFT QVGA LCD Display Screen White LED For Medical Equipment 2


Our Service



At our cross-border e-commerce platform, we take pride in offering exceptional service to our customers, and the CH320QV18A Small TFT LCD Display is just one example of our commitment to excellence.



Our service is centered around delivering high-quality products that meet our customers' unique needs. We understand that every application is different, and that's why we offer a range of customization options for the CH320QV18A Small TFT LCD Display. Whether you need a specific size, shape, or interface, we can work with you to create a display solution that meets your requirements.



We also understand that technical support is crucial for our customers, which is why we offer remote online technical support from our team of skilled engineers. Our engineers can provide assistance with everything from installation to troubleshooting, ensuring that our customers get the most out of their CH320QV18A Small TFT LCD Display.



In addition to our technical support, we also offer professional, one-on-one, 24-hour online customer service. Our team is always available to answer questions, provide guidance, and assist with any issues that may arise. We believe that personalized service is the key to building long-term relationships with our customers, and we strive to provide the best possible experience for each and every one of them.



In summary, our service is designed to provide our customers with the best possible experience, from customized solutions to technical support to reliable supply. We believe that exceptional service is the foundation of our business, and we are committed to delivering it every step of the way.


FAQ



  1. What is the monthly supply capacity of Chenghao Optoelectronic?
    Answer: Chenghao Optoelectronic has a monthly supply capacity of 300K pcs/month.

  2. What certificates do Chenghao Optoelectronic's products provide?
    Answer: All of Chenghao Optoelectronic's products provide RoHS, CE, and FCC certificates, ensuring that they meet international safety and environmental standards.

  3. What kind of technical support does Chenghao Optoelectronic offer?
    Answer: Chenghao Optoelectronic offers remote online technical support from their team of skilled engineers, who can provide assistance with everything from installation to troubleshooting.

  4. What kind of service does the cross-border e-commerce platform offer?
    Answer: The cross-border e-commerce platform offers exceptional service, including customized solutions, remote technical support, 24-hour online customer service, and reliable supply of high-quality products from Chenghao Optoelectronic.
