Custom 256x96 Monochrome LCD Display FSTN 22Pin Graphic Dot Matrix LCD Module

Minimum Order Quantity : 1 pcs Price : /
Packaging Details : All the products are packed in right way to keep it safe. For small sizes of products we use tray + carton, For bigger sizes we use foam slot + carton. we also design packages according to customers' requirements Delivery Time : 7-15 working days
Payment Terms : T/T Supply Ability : 300Kpcs/month
Place of Origin: ShenZhen, China Brand Name: Chenghao/Oem
Certification: ROHS、ISO9001、CE Model Number: CH25696101

Detail Information

Product Name: 256*96 Dot Matrix Graphic LCD Display Modle: FSTN/POSITIVE/TRANSFLECTIVE
Driving Condition: 1/128DUTY,1/12BIAS;VDD=3.3V;VLCD=14.9V Viewing Direction: 6:00 O'clock
Operating Temp: -20~+70°C Storage Temp: -30~+80°C
LCD Connector: COG+FPC IC: ST75256
Backlight: WHITE LED*16;Vf=3.0V;If=240mA
High Light:

256x96 Monochrome LCD Display


FSTN Monochrome LCD Display


22Pin Dot Matrix LCD Module

Product Description

Custom 256*96 Monochrome LCD Display FSTN 22pin Dot Matrix Graphic LCD


1. Specification


Supplier Name Chenghao Optoelectronic --
Lcd No CH25696101 --
Viewing Direction 6:00  o'clock
Operating Temp -20~+70 °C
Storage Temp -30~+80 °C
LCD Connector COG+FPC --
Driver IC ST75256 --


2.Quick detail


Product Name:  7Segment Monochrome LCD Display

Supplier Type: Factory

Method of sales:Wholesale Custom


.Driving Condition:1/128DUTY,1/12BIAS;VDD=3.3V;VLCD=14.9V

Viewing Direction:6:00 o'clock

Operating Temp:-20~+70°C

Storage Temp:-30~+80°C

.LCD Connector:COG+FPC

FPC Number:22

Interface:SPI,MCU/ Cutom

Backlight:16 pcs WHITE LED ;Vf=3.0V;If=240mA

Unspecified tolerance is ±0.20mm


3.Support for custom content:


(1)LCD screen size, material
(2)The type and color of the displayed icon
(3)Backlight brightness, color
(4)Shape structure of FPC
(5)Interface definition


4. Drawings



Custom 256x96 Monochrome LCD Display FSTN 22Pin Graphic Dot Matrix LCD Module 0


5. Applicaion


Chenghao Optoelectronic CH25696101 is a Dot Matrix Graphic LCD with a wide range of applications, such as automation equipment, laboratory instruments, industrial equipment, medical equipment, etc.
