Custom 192x64 Monochrome Graphic LCD Display 12pin FFSTN Dot Matrix Graphic LCD Module

Minimum Order Quantity : 1 pcs Price : /
Packaging Details : All the products are packed in right way to keep it safe. For small sizes of products we use tray + carton, For bigger sizes we use foam slot + carton. we also design packages according to customers' requirements Delivery Time : 7-15 working days
Payment Terms : T/T Supply Ability : 300Kpcs/month
Place of Origin: ShenZhen, China Brand Name: Chenghao/Oem
Certification: ROHS、ISO9001、CE Model Number: CH19264131-WLFW

Detail Information

Product Name: 192x64 Dot Matrix Graphic LCD Display Modle: FFSTN/NEGATIVE/TRANSMISSIVE
Driving Condition: 1/64DUTY,1/9BIAS ;VDD=3.0V,VLCD=10.0V Viewing Direction: 12:00 O'clock
Operating Temp: -10~+60°C Storage Temp: -20~+70°C
LCD Connector: FPC IC: ST7525
Backlight: WHITE LED*5,Vf=3.0V,If=75mA
High Light:

192x64 monochrome graphic LCD display


FFSTN monochrome graphic LCD display


Dot Matrix Graphic LCD Module

Product Description

Custom 192*64 Monochrome LCD Display 12pin FFSTN Negative Dot Matrix Graphic LCD


1. Specification


Supplier Name Chenghao Optoelectronic --
Lcd No CH19264131-WLFW --
Viewing Direction 12:00 o'clock --
Operating Temp -10~+60°C °C
Storage Temp -20~+70°C °C
LCD Connector FPC --
FPC Number 12pin --


2.Quick detail


Product Name:  7Segment Monochrome LCD Display

Supplier Type: Factory

Method of sales:Wholesale Custom

Lcd No:CH19264131-WLFW


Driving Condition:1/64DUTY,1/9BIAS ;VDD=3.0V,VLCD=10.0V

Viewing Direction:12:00 o'clock

Operating Temp:-10~+60°C

Storage Temp:-20~+70°C

LCD Connector:FPC

FPC Number:12pin

Driver IC:ST7525

Backlight:WHITE LED*5,Vf=3.0V,If=75mA

Unspecified tolerance is ±0.20mm

ROHS Request



3.Support for custom content:


(1)LCD screen size, material
(2)The type and color of the displayed icon
(3)Backlight brightness, color
(4)Shape structure of FPC
(5)Interface definition

4. Drawings



Custom 192x64 Monochrome Graphic LCD Display 12pin FFSTN Dot Matrix Graphic LCD Module 0
