128x64 Monochrome LCD Display STN Negative COG Dot Matrix Graphic LCD

Minimum Order Quantity : 1 pcs Price : /
Packaging Details : All the products are packed in right way to keep it safe. For small sizes of products we use tray + carton, For bigger sizes we use foam slot + carton. we also design packages according to customers' requirements Delivery Time : 7-15 working days
Payment Terms : T/T Supply Ability : 300Kpcs/month
Place of Origin: ShenZhen, China Brand Name: Chenghao/Oem
Certification: ROHS、ISO9001、CE Model Number: CH12864356-BIFW

Detail Information

Product Name: 12864 Dot Matrix Graphic LCD Viewing Direction: 6:00 O'clock
Operating Temp: -20~+50°C Storage Temp: -30~+60°C
LCD Connector: COG+FPC IC: ST7567
High Light:

COG Monochrome LCD Display


STN Monochrome LCD Display


Dot Matrix 128x64 monochrome lcd

Product Description

128x64 Monochrome LCD Display STN Negative COG Dot Matrix Graphic LCD


1. Specification


Supplier Name Chenghao Optoelectronic --
Lcd No CH12864356-BIFW --
Viewing Direction 6:00 o'clock
Operating Temp -20~+50 °C
Storage Temp -30~+60 °C
LCD Connector COG+FPC --
FPC Number 30 pin


2.Quick detail


Product Name:  12864 Dot Matrix Graphic LCD

Supplier Type: Factory

Method of sales:Wholesale Custom

Module No: CH12864356-BIFW


Driving Condition:1/64Duty,1/9Bias;VDD=3.3V,VLCD=9.8V

Viewing Direction:6:00 o'clock

Operating Temp:-20~+50°C

Storage Temp:-30~+60°C

LCD Connector: COG+FPC

FPC Number:30pin

Driver IC:ST7567

Backlight:WHITE LED*10,VF=3.0V,IF=150mA

Unspecified tolerance is ±0.30mm

ROHS Request


3.Support for custom content:


(1)LCD screen size, material
(2)The type and color of the displayed icon
(3)Backlight brightness, color
(4)Shape structure of FPC
(5)Interface definition


4. Drawings


128x64 Monochrome LCD Display STN Negative COG Dot Matrix Graphic LCD 0128x64 Monochrome LCD Display STN Negative COG Dot Matrix Graphic LCD 1


5. Our Service


(1)And if it is necessary for you to have technical support in the process of development, we can provide it for you at any time.
(2)Good quality and credit is the soul of our company. Before shipment, we will guarantee that the products will be done the aging test and 100% of the visual and electric logging.
(3)When the product upgrades, we will notify the related clients in advance, and the upgrading product can be perfectly compatible with the old ones.
(4)The warranty period of the product is 12 months.


6. FAQ


Q1: Do you testing the products before shipment?
A: we tested every prodcuts quality before send out .
Q2: What is your payment methods ?
A: T/T,Paypal,West Union and so on .
Q3:What's the lead time?Sample order is available?
A: lead time : 7-15 working days. We don’t have MOQ, Sample order is ok.
Q4:Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings design , we can also build the molds.
Q5. What is your terms of packing?
A: Generally, we pack our goods in standard package , also if you have legally registered patent, we can pack the goods in your branded boxes.
