10.1 Inch Small Color LCD Display 1024x600 50 Pin RGB TFT LCD Module

Minimum Order Quantity : 1PCS Price : /
Packaging Details : All the products are packed in right way to keep it safe. For small sizes of products we use tray + carton, For bigger sizes we use foam slot + carton. we also design packages according to customers' requirements Delivery Time : 7-15 working days
Payment Terms : T/T Supply Ability : 300Kpcs/month
Place of Origin: ShenZhen, China Brand Name: Chenghao/Oem
Certification: ROHS、ISO9001、CE Model Number: CH101WS03B

Detail Information

Product Name: Small Color Lcd Display Module Type: 10.1”TFT
Display Mode: TN/Transmissive/Normally White Number Of Dots: 1024*600
Viewing Direction: 12 O'clock Interface: RGB
Luminace: 300 Cd/m2
High Light:

ROHS Horizontal Small Color LCD Display

,

Small Color LCD Display 1024x600Dots

,

300 cd/m2 tft lcd module

Product Description

10.1 Inch Small Color Lcd Display 1024*600 50 pin Rgb tft lcd module



1. Specification of Tiny Lcd Screen



ITEM STANDARD VALUES UNITS
LCD type 10.1’’TFT --
Dot arrangement 1024(RGB)× 600 dots
Module size 235(W) ×143(H)×5.(T) mm
Active area 223.72(W) ×126.28 (H) mm
Operating temperature - 20 ~ + 70
Storage temperature - 30 ~ + 80
Back Light 36 White LED In Paralle --
Weight TBD g



2. Description of Small Lcd Panel



ChengHao Display model CH101WS03B is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device.

This TFT LCD has a 10.1 (Horizontal screen) inch diagonally measured active display area with 1024*3(RGB)*600 dots resolution.

The driver used for this project can display 16M colors by R.G.B. signal input. The driver is mounted on the glass and the interconnection via FPC including components to drive the display module.

In addition, FPC can also be customized according to customer requirements, such as modifying back-light and FPC structure, interface definition, etc.

RoHS Compliance & Halogen Free.

Note: All our tft lcd modules support touch panel installation.





3. Drawings of Small Lcd Display



Notes:
(1) Display Type : 10.1" Tft lcd
(2) Viewing Direction : 12:00
(4) Polarizer Mode : Tn / Transmissive / Normally While
(5) Operating Temp : -20~70 ℃
(6) Storage Temp : -30~80 ℃
(7) Unmarker Tolerance: ±0.20
(8) Protection : ROHS



10.1 Inch Small Color LCD Display 1024x600 50 Pin RGB TFT LCD Module 0





4. Qucik Detail of Small Lcd Screen



* LCD name: 10.1 Inch Small Color Lcd Display 1024*600 50 Pin Rgb Tft Lcd Module
* Part No.: CH101WS03B
* Size.: 10.1 inch
* Support touch panel Type: No
* Display type: 10.1”TFT
* Display colors: 16M
* Resolution (pixels): 1024*3(RGB)*600
* Viewing direction: 12 O’clock

* Display mode: TN/Transmissive/Normally white
* Overall size: 235*143*5 mm

* Active Area: 222.72*125.28 mm

* Luminance: 300 cd/m2
* Contrast: 500:1
* Interface: RGB
* Pin NO.: 50
* Pin pitch: 0.35 mm
* Backlight : 36 pcs While LED

* Operating temperature: -20 ~ +70

* Storage temperature: -30 ~ +80
