2.8 Inch Custom 240*320 Spi Lcd Module 6 O Clock 4 Lines 8 Bit / 3 Lines 9 Bit

Minimum Order Quantity : 1PCS Price : /
Packaging Details : All the products are packed in right way to keep it safe. For small sizes of products we use tray + carton, For bigger sizes we use foam slot + carton. we also design packages according to customers' requirements Delivery Time : 7-15 working days
Payment Terms : T/T Supply Ability : 300Kpcs/month
Place of Origin: ShenZhen, China Brand Name: Chenghao/Oem
Certification: ROHS、ISO9001、CE Model Number: CH280QV07A

Detail Information

Product Name: 2.8 Inch Custom Lcd Modules LCD Type: 2.8’’TFT
Dot Arrangement: 240(RGB)×320 Dots Color Filter Array: RGB Vertical Stripe
Display Mode: TN / Transmission / Normally White Viewing Direction: 6 O’clock
Gray Scale Inversion Direction: 12 O’clock
High Light:

9 bit spi lcd module

,

2.8inches spi lcd module

,

custom 2.8 inch tft lcd module

Product Description

2.8 Inch Custom Lcd Modules 240*320 6 O'clock 4 Lines 8bit / 3 Lines 9bit Spi Lcd Module



1. Specification



Display type TFT LCD
Backlight tube 4 White LED In Parallel
Brightness (cd/m²) 350
Backlight life (h) 20,000
Contrast 500:1
Viewing angle ( L/R/T/B) 6:00



2. Description



ChengHao Display model CCH280QV07A is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This model is composed of a TFT LCD panel, a driving IC, a high brightness back-light, and FPC.
This TFT LCD has a  2.8 (vertical screen) inch diagonally measured active display area with 240(RGB)x320 Dots .
The driver used for this project is the ILI9341 and can display 65K / 262K / 16M ( Optional ) colors by R.G.B. signal input. The driver is mounted on the glass and the interconnection via FPC including components to drive the display module. Support RGB / SPI interface.
In addition, FPC can also be customized according to customer requirements, such as modifying back-light and CTP structure, interface definition, etc.
RoHS Compliance & Halogen Free.



2.8 Inch Custom 240*320 Spi Lcd Module 6 O Clock 4 Lines 8 Bit / 3 Lines 9 Bit 0







3. Drawings



Notes:
(1) Display Type : 2.8 inch Tft
(2) Viewing Direction : 6:00
(3) Lcd Drive IC : ILI9341
(4) Polarizer Mode : TN / Transmission / Normally White
(5) Operating Temp : -20~70 ℃
(6) Storage Temp : -30~80 ℃
(7) Unmarker Tolerance: ±0.20
(8) Protection : ROHS



2.8 Inch Custom 240*320 Spi Lcd Module 6 O Clock 4 Lines 8 Bit / 3 Lines 9 Bit 1






4. Application



2.8 Inch Custom 240*320 Spi Lcd Module 6 O Clock 4 Lines 8 Bit / 3 Lines 9 Bit 2








5. Products Quality Assurance



(1)High-quality raw material supplier :
after-sales guarantee and long-term stable supplier, LCD panel and Driver IC made of A-regulated raw materials.
(2)Other materials:
such as polarizers, backlight film materials, etc. We also use brand new A-regulated raw materials
(3)Strict quality control:
Through rate up to 98.5%,Customer online defect rate as low as 0.3%.
Inspection is done in FOG==>LCM==>LCM+RTP/CTP==> production online inspection ==>Q.C inspection==>aging test 4 hours with load in 60 ℃ special room (as option)==>OQC.
A product must pass 5 tests before shipment: incoming inspection, 100% online inspection, QC on-site inspection, aging test and OQC inspection, etc.
