Home ProductsTFT LCD Capacitive Touchscreen3.95 Inch ST7701S TFT Resistive Touch Panel 480x800 Pixel Tft Lcd Module
3.95 Inch ST7701S TFT Resistive Touch Panel 480x800 Pixel Tft Lcd Module
3.95 Inch ST7701S TFT Resistive Touch Panel 480x800 Pixel Tft Lcd Module
3.95 Inch ST7701S TFT Resistive Touch Panel 480x800 Pixel Tft Lcd Module 3.95 Inch ST7701S TFT Resistive Touch Panel 480x800 Pixel Tft Lcd Module 3.95 Inch ST7701S TFT Resistive Touch Panel 480x800 Pixel Tft Lcd Module 3.95 Inch ST7701S TFT Resistive Touch Panel 480x800 Pixel Tft Lcd Module
Contact Now

3.95 Inch ST7701S TFT Resistive Touch Panel 480x800 Pixel Tft Lcd Module

Minimum Order Quantity : 1PCS Price : /
Packaging Details : All the products are packed in right way to keep it safe. For small sizes of products we use tray + carton, For bigger sizes we use foam slot + carton. we also design packages according to customers' requirements Delivery Time : 7-15 working days
Payment Terms : T/T Supply Ability : 300Kpcs/month
Place of Origin: ShenZhen, China Brand Name: 4 Inch TFT
Certification: ROHS、ISO9001、CE Model Number: CH400WV13A-CT

Detail Information
Product Name: Small LCD Touch Screen LCD Type: 3.95 Inch
Dot Arrangement: 480(RGB)×800 Color Filter Array: RGB Vertical Stripe
Display Mode: IPS/ Transmissive/ NormallyBlack Viewing Direction: ALL
TFTDriver IC: ST7701S
High Light:

ST7701S TFT Resistive Touch Panel

,

3.95 Inch TFT Resistive Touch Panel

,

480x800 Pixel Tft Lcd Module

Product Description

Customized 3.95 Inch High Resolution Touch Screen All Free Viewing

Direction 480x800 Pixel



 Company Product Category

CHENGHAO OPTOELECTRONIC TFT Display is a professional color LCD display supplier, providing customers with customized services for various small size color LCD screens between 1.1~10.1 inch. The product categories we offer are as follows: 1.1 inch tft display screen, 1.14 inch tft display screen, 1.44 inch tft display screen, 1.47 inch tft display screen, 1.5 inch tft display screen, 1.54 inch tft display screen, 1.77 inch tft display screen, 1.8 inch tft display screen, 2.0 inch tft display screen, 2.1 inch tft display screen, 2.2 inch tft display screen, 2.31 inch tft display screen, 2.4 inch tft display screen, 2.8 inch tft display screen, 3.0 inch tft display screen, 3.2 inch tft display screen, 3.5 inch tft display screen, 3.9 inch tft display screen, 3.95 inch tft display screen, 3.97 inch tft display screen, 4.0 inch tft display screen, 4.3 inch tft display screen, 4.41 inch tft display screen, 4.5 inch tft display screen , 5.0 inch tft display screen, 5.5 inch tft display screen, 6.0 inch tft display screen, 6.8 inch tft display screen, 7.0 inch tft display screen, 8.0 inch tft display screen, 9.0 inch tft display screen, 10.1 inch tft display screen.





1. Specification of Small LCD Touch Screen



               ITEM       STANDARD VALUES UNITS
 LCD type  3.97’’TFT      --
 Dot arrangement  480(RGB)×800    dots
 Color filter array  RGB vertical stripe      --
 Display mode  IPS/ Transmissive/ NormallyBlack      --
 Viewing Direction  ALL      --
 TFTDriver IC  ST7701S      --
 CTPtype  G+F+F      --
 Surface Treatment  6H      --
 CTP Driver IC  GT911      --
 Module size  61.0(W)×102.0(H)×3.7(T)    mm
 TFT/CTPActive area  51.84(W)×86.4(H)    mm
 Dotpitch  0.108(W)×0.108(H)    mm
 Interface  2-lane_MIPI DSI      --
 Operating temperature  -20~+70     ℃
 Storage temperature  -30~ +80     ℃
 Back Light  8 White LED in serial      --
 Weight  TBD       g





2. Quick detail of Small LCD Touch Screen



(1) TFT Notes

  • DISPLAY TYPE:                    3.97"TFT/IPS
  • VIEWING DIRECTION:         ALL
  • LCD DRIVE IC:                     ST7701S
  • POLARIZER MODE:            TRANSMISSIVE/NEGATIVE
  • OPERATING TEMP:             -20°C~+70°C
  • STORAGE TEMP:                 -30°C~+80°C
  • UNMARKER TOLERANCE:  ±0.20
  • Recomnend connector :         AXE 530124
  • REQUIREMENTS ON ENVIRONMENTAL PROTECTION: RoHS

(2) CTP Notes

  • LENS+ITO Film+FPC+adhesive :
    1. ITO Film:             0.45mm
    2. LENS GLASS:    1.1mm
    3. IC:                       GT911
  • Operation Voltage :       2.8V ~ 3.3 V
  • Transmittance :             ≥87%
  • The cover hardness :    6H
  • Operation Temp :         -20~70℃ , ≤ 90% RH
  • Storage Temp :            -30~80℃ , ≤ 90% RH



3. Description of Small LCD Touch Screen



    ChengHao Display model CH400WV13A-CT is a color active matrix thin film transistor (TFT)

liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This model

is composed of a TFT LCD panel, a driving IC, a high brightness back-light, a capacitive touch

panel and FPC.

    This TFT LCD has a 3.97 (16:9) inch diagonally measured active display area with WVGA

(480 horizontal by 800 vertical pixel) resolution.

    The driver used for this project is the ST7701S and can display 16M colors by 24 bit R.G.B.

signal input. The driver is mounted on the glass and the interconnection via FPC including com

-ponents to drive the display module. Support RGB interface.

    In addition, FPC can also be customized according to customer requirements, such as modifying

back-light and CTP structure, interface definition, etc.

    RoHS Compliance & Halogen Free.

3.95 Inch ST7701S TFT Resistive Touch Panel 480x800 Pixel Tft Lcd Module 0



4. Lens Feature of Small LCD Touch Screen

  • Shape : Irregular and hole
  • Color: Silk printing, Logo
  • Glass Materials: Glass, PMMA
  • Treatments: AG, AR, AF, Anti-explosion
  • Thickness: 0. 55mm.0.7mm1.0mm, 1.1mm, 1.8mm, 2.omm,3.0mm, 4. 0mm, 5. 0mm, 6.0mm



5. Customization of Small LCD Touch Screen

3.95 Inch ST7701S TFT Resistive Touch Panel 480x800 Pixel Tft Lcd Module 1



Custom description:

The parts listed above can support customization. If you have more customization needs, please contact our

customer service



6. Advantages of Small LCD Touch Screen



   (1). Why choose ChengHao ?

  • IS9001 Certificated , Factory Direction Supplied
  • RoHs Compliant , Lead Free , Reach Complliant
  • Competitive Price and Short Lead-time
  • Professional Team with Rich Experience in Design / Mfg / Quality Control
  • Small Moq Support & Fast Response to Customers
  • Long-term Supply

(2). Service

  • Warranty: One year .
  • After-sales Service Team: The after-sales service center is equipped with a professional technical service team

   (3). Lead Time

  • 001~20 Pcs (Samples) Immediately
  • 021~100 Pcs 1 Week
  • 101~500 Pcs 1~2 Weeks
  • >1000 Pcs Negotiate

(4). About product certificates



All of our products are passed CE , ROHS , and CE certificates , If you need more information about product

  testing, please contact us !



3.95 Inch ST7701S TFT Resistive Touch Panel 480x800 Pixel Tft Lcd Module 2
(5). Our Main Partners

3.95 Inch ST7701S TFT Resistive Touch Panel 480x800 Pixel Tft Lcd Module 3



7. Application of Small LCD Touch Screen



Application Field Introduction:

Products are widely used in general communications, household appliances, industrial control,
medical equipment, POS machines,instruments, meters, GPS navigation, digital photo frames,
netbooks, financial electronics, communication electronics, consumer electronics, information
appliances, culture, education, sports and entertainment, etc. field. Such as attendance machine,
fingerprint device, access control machine, stock machine, walkie-talkie, video doorbell, learning mach
-ine, point reading machine,GPS navigator, and so on .

3.95 Inch ST7701S TFT Resistive Touch Panel 480x800 Pixel Tft Lcd Module 4





8. FAQ of Small LCD Touch Screen



Q: Are you open to OEM processing?
A: YES!

Q: Payment Terms?
A: Paypal can be accepted for sample, but Credit Card and T/T paid in advance for mass production.
Q: What is your delivery method?
A: DHL/ UPS / FEDEX/TNT , Or ship the goods to your HK forwarder.
Q: Products are in stock?
A: Our inventory is mainly raw materials,semi-finished and a small amount of finished products.
Q: How long can you deliver?
A: After payment, Samples available in stock will be sent within 3 days; Small batch delivery takes 2-3
weeks; Large batch delivery takes 5-6 weeks
Q: What kind of packaging? The transport process will not be damaged?
A: Our products are divided into two categories, small - medium size use knife card isolation packaging,
large size screens are used in aircraft box packaging, all packages are protected by outer box and strapping to ensure the safety of material
transportation.
Q:How to control the quality of products?
A: The company has a professional quality team, and all products are 100% inspected before shipment.
Q: How long is the warranty and service of the product?
A: Generally the warranty period is one year. It depends on different products.
We guarantee our products to be free from manufacturer defects. Liability under this warranty is limited to the replacing of any product found to be defective under normal use.
Q: What certification could provide ?
A: Products by RoHS, CE, ISO9001 certification.
Q: Can you provide product drawings and test reports?
A: According to customer needs, our company can provide product related information and test reports.
Q: The product specification is in Chinese or English?
A: The version of product specification is English.
